Page 1

background image

ECCS (Engine Management) Relay: Locations
After Engine KA24-012039

Fig 1 Component Locations

Powertrain Management
Computers and Control Systems
Relays and Modules - Computers and Control Systems
ECCS (Engine Management) Relay <--> [Main Relay (Computer/Fuel System)] / Component Information
Locations
After Engine KA24-012039
