Armada 4WD V8-5.6L (VK56DE) Flex Fuel (2009)
Air Door Actuator / Motor: Service and Repair
Defroster Door Motor
DEFROSTER DOOR MOTOR
Removal and Installation
Defroster Door Motor - Front Heater and Cooling Unit Assembly
REMOVAL
1. Remove the BCM. Refer to See: Body and Frame/Body Control Systems/Body Control Module/Service and Repair.
2. Remove the Bose speaker amplifier if equipped. Refer to See: Accessories and Optional Equipment/Radio, Stereo, and Compact
Disc/Amplifier/Service and Repair/Bose Audio Without Navigation.
3. Disconnect the defroster door motor electrical connector.
4. Remove the three screws and remove the defroster door motor.
INSTALLATION
Installation is in the reverse order of removal.
