Refrigerant Oil: Capacity Specifications

Lubricant

Total in system ...............................................................................................................................................................  120 ml (4.1 US fl oz, 4.2 Imp fl oz)

Compressor (service part) charging amount ..................................................................................................................  120 ml (4.1 US fl oz, 4.2 Imp fl oz)

Fill with lubricant for the amount that is calculated according to the following conditions.

Example: Lubricant amount to be added when replacing evaporator and liquid tank [ml (US fl oz., Imp fl oz.)] = 35 (1.2, 1.2) + 5 (0.2, 0.2) + a
