Pathfinder 4WD V6-4.0L (VQ40) (2005)
/Page-598001.png)
Camshaft Bearing: Specifications
Camshaft Bearing Cap
Tighten camshaft bracket bolts in the following steps, in numerical order as shown.
Camshaft bracket bolts
Step 1 (bolts 7 - 10) ........................................................................................................................................................ 1.96 Nm (0.2 kg-m, 17 inch lbs.)
Step 2 (bolts 1 - 6) ......................................................................................................................................................... 1.96 Nm (0.2 kg-m, 17 inch lbs.)
Step 3 ............................................................................................................................................................................ 5.88 Nm (0.6 kg-m, 52 inch lbs.)
Step 4 ............................................................................................................................................................................ 10.4 Nm (1.1 kg-m, 92 inch lbs.)
