Pathfinder 4WD V6-4.0L (VQ40) (2005)
/Page-671001.png)
Intake Manifold: Specifications
Tightening Torques & Sequences
Intake Manifold
^
Tighten all nuts and bolts to the specified torque in two or more steps in numerical order as shown.
Intake manifold bolt and nuts
1st step .......................................................................................................................................................................... 7.4 Nm (0.75 kg-m, 5 ft. lbs.)
2nd step and after ....................................................................................................................................................... 29.0 Nm (3.0 kg-m, 21 ft. lbs.)
