Detonation Control Unit <--> [Electronic Spark Control Module]: Locations
- Make
- Nissan and Datsun
- Model
- PL720 4WD
- Engine
- L4-2389cc 2.4L SOHC (Z24)
- Year
- 1983
- Section
- Relays and Modules - Computers and Control Systems › Detonation Control Unit <--> [Electronic Spark Control Module] › Locations
Relays and ModulesLocations
Detonation Control Unit <--> [Electronic Spark Control Module]: Locations – diagram from the Relays and Modules chapter of the Nissan PL720 4WD L4-2389cc 2.4L SOHC (Z24) (1983) factory manual.
![Diagram: Detonation Control Unit <--> [Electronic Spark Control Module]: Locations – Nissan PL720 4WD L4-2389cc 2.4L SOHC (Z24) (1983)](/nissan/pl720_4wd/l4-2389cc_2.4l_sohc_(z24)/Page-9001.png)
Detonation Control Unit: Locations
Chassis Components.
Under Driver's Seat
Applicable to: 1983-84 Pickup
