Windshield Washer Switch: Service and Repair

FRONT WIPER AND WASHER SYSTEM

Removal and Installation of Front Wiper and Washer Switch

REMOVAL
1. Remove the steering column cover.  See: Body and Frame/Interior Moulding / Trim/Dashboard / Instrument Panel/Service and Repair/Component

Parts .

2. Disconnect the wiper and washer switch connector.

3. Pull wiper and washer switch (1) toward the passenger door while pressing pawls (A) in direction shown by the arrow, and remove it from the

base.

INSTALLATION
Installation is in the reverse order of removal.
