Antenna, Phone: Service and Repair

TEL ANTENNA

Removal and Installation

REMOVAL
1. Remove the RH front seat. Refer to See: Body and Frame/Seats/Service and Repair/Front Seat/Removal and Installation.
2. Disconnect the Bluetooth antenna harness connector.
3. Remove the Bluetooth antenna screws, then remove the Bluetooth antenna.

INSTALLATION
Installation is in the reverse order of removal.
