Cutlass Supreme FWD V6-204 3.4L DOHC (1991)
Power Window Motor: Service and Repair
Power Window and Door Switch Assembly
Coupe
POWER WINDOW AND DOOR SWITCH ASSEMBLY - COUPE
NOTICE: When removing a door trim panel or switch plate, the ignition switch must be in the off position. This will eliminate the possibility of
shorting out the switch if a screwdriver, awl or metal object is used to remove the switch from the harness.
Power Switch Assembly - Coupe
REMOVE OR DISCONNECT
1. Retractor cover.
2. Switch assembly by prying up with a flat-bladed tool.
3. Clips.
4. Connectors.
INSTALL OR CONNECT
1. Connectors.
2. Clips.
3. Switch assembly by pressing in place.
4. Retractor cover.
Front Door
POWER WINDOW AND DOOR SWITCH ASSEMBLY - SEDAN FRONT DOOR
NOTICE: When removing a door trim panel or switch plate, the ignition switch must be in the OFF position. This will eliminate the possibility of
shorting out the switch if a screwdriver, awl or metal object is used to remove the switch from the harness.
