6000 V6-173 2.8L (1988)
^
Adjust front corners of glass panel so that it is flush to 1.5 mm (flush to 0.060") BELOW roof panel. Refer to Figure 5.
^
Adjust rear corners of glass panel so that it is flush to 1.5 mm (flush to 0.060") ABOVE roof panel. Refer to Figure 5.
Fore/Aft Specification:
^
The sliding glass panel weatherstrip seal should make continuous contact with the roof panel around the entire sunroof opening. To check for
contact, completely close the sunroof and insert a business card or 0.040" thickness gage between the sunroof seal and roof panel. Check for
seal-to-roof panel contact by sliding the card around the entire seal contact area. The card should drag slightly as it is pulled between the seal and
the roof panel.
^
If the gap is excessively wide or narrow at the front or rear, adjust the glass panel fore/aft position as described in the appropriate Pontiac Service
Manual.
Parts are currently available from GMSPO.
Use applicable labor operation.
Black Max is a trademark of Loctite Corporation, and Loctite is a registered trademark of Loctite Corporation.
