Alignment: Specifications



Caster Angle

+2.5 to +3.5 deg









Desired Caster

3 deg









Camber Angle

Left

0 to +1 deg









Right 0 to +1 deg















Desired Camber Angle

Left

0.5 deg









Right 0.5 deg

















Toe

1/16 to 3/16 in
