Drive Belt: Testing and Inspection (page 2 of 3)
- Make
- Pontiac
- Model
- G5
- Engine
- L4-2.2L
- Year
- 2007
- Section
- Drive Belt
MaintenanceTesting and Inspection · page 2 of 3
Drive Belt: Service and Repair
Drive Belt Replacement
Tools Required
J 44811 Accessory Belt Tensioner Unloader
Removal Procedure
1. Remove the engine splash shield.
2. Install the J 44811 to the drive belt tensioner.
3. Using the J 44811, rotate the tensioner counterclockwise in order to release the tensioner from the drive belt.
4. Remove the drive belt.
5. Slowly rotate the J 44811 and the tensioner clockwise in order to allow the tensioner to rest.
6. Remove the J 44811 from the drive belt tensioner.
Installation Procedure
