G5 L4-2.2L (2007)
Fuel Filler Hose: Service and Repair
Fuel Tank Filler Pipe Replacement
Fuel Tank Filler Pipe Replacement
Removal Procedure
Caution: Refer to Gasoline/Gasoline Vapors Caution.
1. Remove the fuel fill cap.
2. Drain the fuel tank. Refer to Fuel Tank Draining.
3. Remove the fuel fill pocket.
4. Raise and support the vehicle. Refer to Vehicle Lifting.
5. Disconnect the fuel fill vent pipe quick connect fitting (1) from the evaporative emission (EVAP) canister.
6. Cap or plug the EVAP canister fitting in order to prevent system contamination.
