G6 L4-2.4L (2007)
![background image](/pontiac/g6/l4-2.4l/Page-491001.png)
Drive Belt: Service and Repair
Drive Belt Replacement
Tools Required
J 44811 Accessory Belt Tensioner Unloader
Removal Procedure
1. Remove the air cleaner outlet resonator.
2. Remove the right front fender liner.
3. Install the J 44811 to the drive belt tensioner.
4. Using the J 44811 , rotate the tensioner counterclockwise in order to release the tensioner from the drive belt.
5. Remove the drive belt.
6. Slowly rotate the J 44811 and the tensioner clockwise in order to allow the tensioner to rest.
7. Remove the J 44811 from the drive belt tensioner.
Installation Procedure
