G6 V6-3.5L VIN 8 (2005)
Ignition Switch Lock Cylinder: Service and Repair
Ignition Switch Lock Cylinder - Dash Mounted
Ignition Switch Lock Cylinder Replacement
Removal Procedure
1. Remove the knee bolster.
2. Turn ignition switch to the run position.
3. Push the ignition lock cylinder tab.
4. Remove the ignition lock cylinder.
Installation Procedure
Important: If you are installing a new lock cylinder, refer to Key and Lock Cylinder Coding.
