G6 V6-3.6L (2007)
![background image](/pontiac/g6/v6-3.6l/Page-510001.png)
Drive Belt: Service and Repair
Drive Belt Replacement
Removal Procedure
1. Remove the air cleaner assembly.
2. Remove the engine mount strut bracket.
3. Using a long breaker bar, rotate the drive belt tensioner clockwise to release the drive belt tension.
4. Slide the drive belt off of the belt idler pulley (1).
5. Slowly release the drive belt tensioner.
6. Remove the drive belt from the accessory drive pulleys.
Installation Procedure
