G6 V6-3.6L (2007)
Case: Service and Repair
4T45-E - Automatic Transaxle
Case Side Cover Replacement
Removal Procedure
1. Remove the battery tray assembly.
2. Disconnect the shift cable from the park neutral position (PNP) switch.
3. Remove the shift cable bracket.
4. Remove the PNP switch lever nut and lever.
