G6 V6-3.6L (2007)
Clutch Disc: Service and Repair
Clutch Drive Plate and Clutch Driven Plate
Tools Required
J 29074-A Clutch Alignment Arbor
Removal Procedure
1. Remove the transmission. Refer to Transmission Replacement.
2. Remove the clutch cover bolts one turn at a time, until spring pressure is relieved.
3. Remove the clutch cover and the clutch disc.
Installation Procedure
1. Align the heavy side of the flywheel assembly, stamped with an X, with the clutch cover light side, marked with paint.
