Grand AM L4-121 2.0L (1988)
Dash Board / Instrument Panel: All Technical Service Bulletins
Instrument Panel - Noise Coming From Center Area
Bulletin Number:
88-10-26A
Reference Number:
871201R
Publish Date:
6/88
Subject:
RATTLE OR BUZZING NOISE COMING FROM CENTER AREA OF INSTRUMENT PANEL
Models 1987-88 SUNBIRD AND GRAND AM
Affected:
EQUIPPED WITH C60
"This bulletin is being revised to add a labor operation number and Labor time.. Please discard bulletin 88-10-26, dated 4/88."
Some Sunbird and Grand Am car owners may comment on a metallic rattle or buzzing noise coming from center of the instrument panel.
Under certain road or engine load conditions, with the AC system on, the metal defroster valve in the AC module assembly may vibrate against the
plastic case causing the noise. The noise may be heard in all modes except defrost.
FIGURE 1
The following procedure should be followed to address this condition:
CORRECTION:
1.
Remove right side insulator assembly. SEE FIGURE 1.
FIGURE 2
2.
Remove duct assembly, floor air outlet. SEE FIGURE 2.
3.
Secure a 1" long piece of 7/16" windshield washer hose (or equivalent) and cut one side the full 1" length so that the hose can be slipped over the
edge of the defroster valve.
