Grille: Service and Repair
Front Bumper Fascia Grille Replacement - Lower (Base)
Removal Procedure
1. Apply masking tape around the grille to protect the paint and fascia.
Notice: Refer to Exterior Trim Emblem Removal Notice in Service Precautions.
2. Use a plastic, flat-bladed tool to lift the edge of the grille from the fascia.
3. Pull outward on the grille to release the grille tabs from the front bumper fascia.
4. Remove the grille from the front bumper fascia.
Installation Procedure
