Air Flow Meter/Sensor: Locations

Engine Controls Component Views

Left Top Side of Engine

Left Top Side Of Engine

1 - Throttle Actuator Control (TAC) Module
2 - Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor
3 - Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor Connector
