Montana SV6 V6-3.9L (2007)
Cowl: Service and Repair
Windshield Lower Panel Replacement
Removal Procedure
Caution: Refer to Approved Equipment for Collision Repair Caution.
Important: When replacing panels that involve servicing of stationary glass, refer to Urethane Adhesive Installation of Stationary Windows
before performing any priming or refinishing.
1. Disable the SIR system.
2. Disconnect the negative battery cable.
3. Remove all related panels and components.
4. Repair as much of the damage as possible to factory specifications.
Caution: Refer to Foam Sound Deadeners Caution.
5. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary.
6. Remove the windshield.
Important: Do not damage any inner panels or reinforcements.
7. Locate and drill out all factory welds. Note the number and location of welds for installation of the new panel.
8. Remove the damaged panel.
Installation Procedure
