Parisienne V6-262 4.3L (1986)
Figure 4 - Control Valve Assembly Exploded
Beginning on October 21, 1985, or Julian Date 294 (refer to Figure 1) all 1986 THM 700-R4 transmissions have been built with control valve assemblies
that do not use a throttle valve sleeve (refer to item #327 in Figure 2) with the throttle valve (item #326). When servicing 1983 through 1985 model year
transmissions this new assembly will be used when current service parts stock is depleted.. In order to update the appropriate 1986 Service Manual,
revised illustrations (refer to Figures 3, 4) have been provided.
