Vibe L4-1.8L VIN L (2003)
Sun Visor: Removal and Replacement
Sunshade Replacement
Sunshade Replacement
Removal Procedure
1. Fold sunvisor down to access screws.
2. Remove the following components from the vehicle:
*
The 2 screws (1)
*
The sunshade (2)
Installation Procedure
1. Install the sunshade (2) to the vehicle. Secure the sunshade with the 2 screws (1).
2. Fold sunvisor back to up right position.
Sunshade Anchor Replacement
Sunshade Anchor Replacement
Removal Procedure
1. Position the sunshade as necessary in order to gain access to the sunshade anchor.
2. Turn the sunshade anchor, by turning it 90 degrees counter clockwise.
3. Remove the sunshade anchor.
Installation Procedure
