Vibe L4-1.8L VIN L (2003)
Keyless Entry Receiver: Description and Operation
REMOTE CONTROL DOOR LOCK RECEIVER
The remote control door lock receiver (1) is located in the upper right quarter panel. The receiver directly controls the functions of the keyless entry
system.
The receiver is able to receive signals from up to four transmitters, and must be programmed to accept signals from any transmitters that are to be
added or replaced.
