Vibe L4-1.8L VIN L (2003)
Crankshaft Main Bearing Seal: Service and Repair
Crankshaft Rear Oil Seal Replacement
Removal Procedure:
Caution: Refer to Battery Disconnect Caution in Service Precautions.
1. Disconnect the negative battery cable.
2. Remove the transaxle assembly.
3. If equipped with a manual transmission, remove the clutch and pressure plate.
4. Remove the flywheel from the crankshaft.
Important: To protect the crankshaft from damage wrap the tip of the screwdriver with tape.
5. Use a screwdriver and pry out the crankshaft rear oil seal.
Installation Procedure
