Vibe L4-1.8L VIN L (2003)
![background image](/pontiac/vibe/l4-1.8l_vin_l/Page-1812001.png)
Seat Belt Buckle: Service and Repair
Seat Belt Buckle Replacement - Rear
REMOVAL PROCEDURE
1. Remove the rear seat.
2. Remove the following components from the vehicle:
-
The anchor bolt
-
The rear seat belt buckle (1)
INSTALLATION PROCEDURE
1. Install the rear seat belt buckle (1) to the vehicle. Secure the buckle with the anchor bolt.
NOTE: Refer to Fastener Notice in Service Precautions.
Tighten
Tighten the rear seat belt buckle anchor bolt to 42 N.m (31 lb ft).
2. Install the rear seat.
