Vibe AWD L4-2.4L (2009)
Stabilizer Bushing: Service and Repair
Front Suspension
Stabilizer Shaft Insulator Replacement
Removal Procedure
1. Lower the following components as an assembly as far as necessary in order to access the stabilizer shaft insulators. Refer to Front Suspension
Crossmember Replacement (All Wheel Drive) (See: Cross-Member/Front Cross-Member/Service and Repair)Front Suspension Crossmember
Replacement (Two Wheel Drive) (See: Cross-Member/Front Cross-Member/Service and Repair).
*
The front suspension crossmember
*
The trans support
*
The front control arms
*
The stabilizer shaft
*
The stabilizer shaft links
*
The stabilizer shaft clamps
*
The stabilizer shaft insulators
2. Remove the 4 bolts from the stabilizer shaft clamps.
3. Remove the 2 stabilizer shaft clamps.
4. Remove the 2 stabilizer shaft insulators.
Installation Procedure
1. Position the stabilizer shaft on the crossmember.
