911 GT2 (996) F6-3.6L Turbo (2003)
Gateway
The gateway is integrated in the PCM2/CDR23. Together with the MMI it is a fixed component of each PCM2/CDR23. It provides a connection to CAN
Comfort via its nodes. Diagnosis and useful data is exchanged with CAN via these nodes.
It creates links to the following systems:
-
CAN Comfort
-
Media Oriented Systems Transport (MOST), external bus (optical)
-
Amplifier optional (Harman or BOSE)
-
CD changer
-
Telephone/telematics
Applies Only To PCM2:
-
Media Oriented Systems Transport (MOST), internal (electrical)
-
Voice control system (VOCS) (optional/insertion)
-
Navigation (optional/rack)
-
Man Machine Interface (MMI)
-
Single CD
Identification
The diagnosis software number and the part numbers for the PCM2 can be read out under this menu item.
