911 Targa 4S (997) F6-3.8L (2007)
1. Lay rear wire harness in interior of vehicle and push it into the engine compartment through the opening in the rear wall. Lay rear wire harness in
engine compartment.
2. Plug in connector on reversing light switch -28- until it engages correctly.
3. Screw down B+ lead -27- on transmission.
-
Tightening torque: 10 Nm (7.5 ftlb.)
4. Plug in connector on rear antenna for tyre pressure monitoring system -26- at left and right.
4.1. Fit rubber sleeve -30-.
4.2. Plug in connector on rear antenna for tyre pressure monitoring system -26- at left and right until it engages securely.
4.3. Clip tie-wrap -31- into place.
5. Connect plug connection for rear wheel sensor -25- at left and right.
5.1. Fit rubber sleeve -30-.
5.2. Place socket in installation position -arrow A- and screw on the fastening nut.
