Cayman S (987) F6-3.4L (2008)
8. Remove tool. Loosen the large hexagon-head bolt and the two inner hexagon-head bolts alternately on the crankshaft flange until the tool can be
removed.
9. Check whether the sealing ring is properly seated and aligned. To do this, measure at four points, offset by 90°, from the flywheel attachment
surface on the crankshaft flange to the sealing ring (outer radius). -> Dimension: 13 mm
10. Leave supporting sleeve on the tool following assembly to protect the edges of the tool. Carefully lift off the sleeve at the bore with a small
screwdriver to remove it.
Subsequent work for crankshaft sealing ring on flywheel side
Subsequent work for crankshaft sealing ring on flywheel side Manual transmission:
1. Install double-mass flywheel.
2. Install clutch.
3. Install manual transmission.
Tiptronic:
4. Install drive plate for converter.
5. Install automatic transmission.
