9000 L4-2290cc 2.3L DOHC Turbo EFI (1992)
Housing Assembly HVAC: Description and Operation
Defrost
Damper angle 135° for both automatic and manual control.
Defrost, floor
Damper angle 112.5° for manual or 112.5° - 135° for automatic control. During both automatic and manual control.
