Astra L4-1.8L (2009)
Sun Visor: Service and Repair
Sunshade Anchor Replacement
Sunshade Anchor Replacement
Removal Procedure
Important: The spring of the main bracket is not secured and may fall down.
Remove the sunshade support.
*
Release the sunshade.
*
Release the main bracket wedge and remove the main bracket.
Installation Procedure
Install the sunshade support.
*
Install the wedge with the groove downwards.
*
Install the sunshade into the main bracket.
