Astra L4-1.8L (2009)
Trim Panel: Service and Repair
Cargo Net Bracket Replacement
Cargo Net Bracket Replacement
Removal Procedure
Remove the luggage retaining net bracket.
*
Remove the bolt.
*
Remove the cargo net bracket.
Installation Procedure
1. Install the cargo net bracket.
Caution: Refer to Fastener Caution (See: Service Precautions/Vehicle Damage Warnings/Fastener Caution).
Note: Bolts are inserted with locking compound.
2. Install the cargo net bracket.
Tighten the bolt to 20 Nm (15 lb ft).
