Astra L4-1.8L (2009)
Headlamp Washer Pump: Service and Repair
Headlamp Washer Pump Replacement
Removal Procedure
Important: Drain the washer solvent into a suitable container.
Remove the pump for the headlamp washer system (1).
*
Disconnect the hose (3).
*
Remove the washer pump upward.
*
Disconnect the wiring harness plug (2).
Installation Procedure
