Aura L4-2.4L Hybrid (2009)
Front Bumper Bracket: Service and Repair
Front Bumper Impact Bar Bracket Replacement
Front Bumper Impact Bar Bracket Replacement
Removal Procedure
Warning: Refer to Approved Equipment for Collision Repair Warning (See: Service Precautions/Technician Safety Information/Approved
Equipment for Collision Repair Warning).
1. Disable the SIR system. Refer to SIR Disabling and Enabling (See: Interior Moulding / Trim/Dashboard / Instrument Panel/Air Bag(s) Arming
and Disarming/Service and Repair).
2. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection (LAT) (See: Starting and
Charging/Battery/Battery Cable/Service and Repair)Battery Negative Cable Disconnection and Connection (LZ4, LY7, and LE5) (See: Starting
and Charging/Battery/Battery Cable/Service and Repair).
3. Remove all related panels and components.
4. Repair as much of the damage as possible. Refer to Dimensions - Body ().
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to Anti-Corrosion Treatment and Repair ().
