Aura L4-2.4L Hybrid (2009)
Cabin Ventilation Grille: Service and Repair
Pressure Relief Valve Replacement
Removal Procedure
1. Raise the vehicle. Refer to Lifting and Jacking the Vehicle (See: Maintenance/Vehicle Lifting/Service and Repair).
2. Remove the rear fascia. Refer to Rear Bumper Fascia Replacement (See: Bumper/Rear Bumper/Rear Bumper Cover / Fascia/Service and Repair).
3. Remove the pressure relief valve from under vehicle, behind rear fascia.
Installation Procedure
1. Install the pressure relief valve.
2. Install the rear fascia. Refer to Rear Bumper Fascia Replacement (See: Bumper/Rear Bumper/Rear Bumper Cover / Fascia/Service and Repair).
3. Lower the vehicle.
