Aura L4-2.4L Hybrid (2009)
Variable Valve Timing Actuator: Service and Repair
Camshaft Position Intake Actuator Replacement
Camshaft Position Intake Actuator Replacement
Special Tools
*
EN-48749 Timing Chain Retention Tool Kit
*
EN-48953 Camshaft Actuator Locking Tool
*
J 45059 Angle Meter
Removal Procedure
1. Remove the camshaft cover. Refer to Camshaft Cover Replacement (See: Engine, Cooling and Exhaust/Engine/Cylinder Head Assembly/Valve
Cover/Service and Repair).
2. Remove the upper timing chain guide bolts and guide.
