Saturn Workshop Service and Repair Manuals > Sedan L4-1.9L DOHC VIN 7 (1994) > Relays and Modules | Relays and Modules - Transmission and Drivetrain | Relays and Modules - A/T | Control Module, A/T | Component Information | Diagrams | J1 Connector

J1 Connector|Page 220 > < Passive Restraint Module <--> [Seat Belt Control Module]|Locations|Page 213

Page 1

background image

PCM Connector Pinout.

Relays and Modules
Relays and Modules - Transmission and Drivetrain
Relays and Modules - A/T
Control Module, A/T
Component Information
Diagrams
J1 Connector

J1 Connector|Page 220 > < Passive Restraint Module <--> [Seat Belt Control Module]|Locations|Page 213
