VUE 2WD V6-3.5L VIN 4 (2004)
Air Dam: Service and Repair
Air Deflector Replacement - Front Bumper Fascia
Removal Procedure
1. Remove the front air deflector to fascia screws.
2. Remove the front air deflector to engine cradle push-in retainers.
3. Remove the front air deflector by lowering from the vehicle.
Installation Procedure
1. Align the front air deflector to the fascia.
Notice: Refer toFastener Notice in Cautions and Notices.
2. Install the front air deflector to fascia screws.
