VUE 2WD V6-3.5L VIN 4 (2004)
13. Remove the ONSTAR mounting bracket bolts and J-nuts from the brake pedal assembly, if equipped.
Installation Procedure
Notice: Refer to Fastener Notice in Service Precautions.
1. Install the ONSTAR (R) J-nuts and mounting bracket bolts to the brake pedal assembly, if equipped.
^
Tighten the bolts to 10 Nm (89 inch lbs.).
2. Install the accelerator pedal assembly to the brake pedal bracket.
