VUE AWD V6-3.5L VIN 4 (2004)
Air Register: Service and Repair
Air Outlet Duct Replacement - Center
AIR OUTLET DUCT REPLACEMENT - CENTER
REMOVAL PROCEDURE
1. Remove the instrument panel retainer.
2. Remove the center air outlet duct push pins from the cross car beam.
3. Remove the center air outlet duct from the cross car beam.
INSTALLATION PROCEDURE
1. Inspect the seals and replace if damaged using Kent Industries adhesive backed foam tape P/N 46485 or equivalent.
2. Install the center air outlet duct to the cross car beam.
3. Install the center air outlet duct push pins to the cross car beam.
4. Install the instrument panel retainer.
