VUE AWD V6-3.5L VIN 4 (2004)
9. Remove the TXV bolts from the backing plate.
10. Remove the TXV and the backing plate from the vehicle.
11. Remove and discard the O-rings from the evaporator pipes.
12. Install a protective cap to the evaporator pipes to prevent contamination and desiccant saturation.
INSTALLATION PROCEDURE
1. Remove the protective caps from the evaporator pipe and ensure the seal areas are clean, dry and lint free.
IMPORTANT: Use only lint free cloths to wipe parts. Do not allow any solvent to enter evaporator or hoses.
2. Install new O-rings to the evaporator pipes.
3. Remove the protective caps from the TXV.
4. Install the TXV and the backing plate to the evaporator pipes.
NOTE: Refer to Fastener Notice in Service Precautions.
5. Install the TXV bolts to the backing plate.
