VUE AWD V6-3.5L VIN 4 (2004)
Receiver Dryer: Service and Repair
RECEIVER DEHYDRATOR REPLACEMENT
TOOLS REQUIRED
J 39400-A Halogen Leak Detector
REMOVAL PROCEDURE
1. Recover the refrigerant. Refer to Refrigerant Recovery and Recharging.
2. Remove the left headlamp assembly.
3. Remove the receiver dehydrator nut from the condenser.
IMPORTANT: Use a large pair of pliers to hold the fitting. Be careful not to twist the line.
4. Remove the receiver dehydrator nut from the liquid line.
IMPORTANT: Use a large pair of pliers to hold the fitting. Be careful not to twist the line.
