VUE FWD V6-3.6L Hybrid (2009)
Heater Core: Service and Repair
Heater Core Replacement
Removal Procedure
1. Remove the HVAC module from the vehicle. Refer to Air Conditioning and Heater Module Assembly Replacement (See: Heating and Air
Conditioning/Housing Assembly HVAC/Service and Repair/Air Conditioning and Heater Module Assembly Replacement).
2. Remove the heater core cover screws from the HVAC module.
3. Remove the heater core cover from the HVAC module.
4. Remove the heater core from the HVAC module.
Installation Procedure
