VUE FWD V6-3.6L Hybrid (2009)
Valve Cover: Service and Repair
Camshaft Cover Replacement - Left Side
Camshaft Cover Replacement - Left Side
Special Tools
EN 46101
Removal Procedure
1. Remove the left bank spark plugs. Refer to Spark Plug Replacement (See: Tune-up and Engine Performance Checks/Spark Plug/Service and
Repair)
2. Reposition ignition coil wire harness aside.
3. Remove the left camshaft cover bolts.
4. Remove the left camshaft cover from the left cylinder head.
5. Clean the mating surfaces of the cylinder head and the camshaft cover. Refer to Camshaft Cover Cleaning and Inspection ()
