VUE FWD V6-3.6L Hybrid (2009)
Vehicle Speed Sensor: Service and Repair
Vehicle Speed Sensor Replacement
Removal Procedure
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle (See: Maintenance/Vehicle Lifting/Service and Repair).
2. Remove the vehicle speed sensor (VSS) electrical connector (1) from the VSS.
3. Remove the VSS electrical harness retainer (2) from the VSS.
4. Remove the retaining stud and the VSS. Pull straight out in order to avoid damage to the case.
Installation Procedure
1. Clean and dry the VSS.
