xB L4-1.5L (1NZ-FE) (2004)
/Page-811001.png)
Brake Master Cylinder: Service and Repair
BRAKE MASTER CYLINDER SUB-ASSY
REPLACEMENT
1. DRAIN BRAKE FLUID
NOTICE: Wash the brake fluid off immediately if it adheres to any painted surfaces.
2. REMOVE AIR CLEANER CAP SUB-ASSY
3. DISCONNECT CLUTCH RESERVOIR TUBE (M/T TRANSAXLE)
a. Slide the clip and disconnect the clutch reservoir tube.
4. REMOVE BRAKE MASTER CYLINDER
