xB L4-1.5L (1NZ-FE) (2004)
/Page-1068024.png)
NOTE:
^
Check that the top ends of the air mix door lever and the max cool switch lever are almost flush.
^
If the top ends of the air mix door lever and the max cool switch lever are NOT flush, adjust the height by bending the air conditioner
accessory assembly bracket.
7.
Install NEW cooler wiring No. 2.
A.
Route the foot defrost switch around the backside of the defroster nozzle and install it with the 2 screws.
