xB L4-1.5L (1NZ-FE) (2004)
/Page-233022.png)
2.
Remove the air conditioning amplifier assembly.
A.
Disconnect the connector.
B.
Remove the 2 screws and air conditioning amplifier assembly.
NOTE:
Remove the air conditioning amplifier bracket, as only the air conditioning amplifier will be reused.
3.
Remove the air mix damper control cable Sub-assembly.
A.
Disconnect the outer cable.
B.
Disconnect the inner cable and remove the air mix damper control cable sub-assembly.
4.
Remove cooler wiring No. 2.
A.
Remove the 5 screws and the cooler wiring No. 2.
NOTE:
^
Remove the brackets from the connector and reinstall them to the heater radiator assembly, as the brackets will be reused.
^
Cut the wire harness in the switch area and remove the cooler wiring No. 2 from the heater unit.
